DBH D6 Thermal Imaging Riflescope

CORE CHARACTERISTICS

Sensor Resolution: 640×512

Objective Lens: 60mm

Optical Zoom: 3

Display Resolution: 2560 x 2560

Operating Time: 8h

Model		DBH D6
Sensor Specifications	Type	VOx Uncooled
	Resolution, pixels	640×512
	Pixel pitch, μm	12
	NETD, mK	<20
	Frame Rate, Hz	60

Optical Specifications	Objective Lens，mm	60 F1.0
	Optic Zoom, x	3
	Field of View, degrees / yd @ 100 yd	7.3°×5.8°
	Digital Zoom, x	1 to 6
	Eye Relief, mm	60
	Diopter Adjustment, D	-5 to +2
	Detection Range, m/yd	3280

Display Specifications	Type	OLED
Display Specifications	Resolution, pixels	2560 x 2560

Wi-Fi	Wireless Protocol	Wi-Fi
Wi-Fi	Frequency, GHz	2.4GHz

Video Recorder	Video / Photo Resolution, pixel	1280×1280
	Video / Photo Format	.mp4 / .jpg
	Built-in Memory, GB	64

Physical Specifications	Degree of Protection, IP code	IP67
	Operating Temperature Range, °F	-13 to+122
	Weight, lb	2.9
	Dimensions, inch	10.3×3.3×3.8

Connections and Compatibilities	Battery Type	18650
	Operating Time on Battery Pack (at t=72°F), h	8
	External Power Supply, V	5V (Type C USB)
	Max Recoil Power on Rifled Weapon (Eo), g/Joules	1000g/6000Joules
	Ballistic calculation	Yes
